J30J-25ZKSL Micro-D Connector | 25-Pin 5A MDM Series Rectangular Receptacle

Part Number:J30J-25ZKSL

Product Description:

MIL-DTL-83513 Micro-D Connectors

The MDM Series of Micro-D Connectors are designed for high performance and reliability in a miniature package. These connectors are commonly used in military and aerospace applications, as well as in high-tech electronics and communication systems. The MDM Series offers a wide range of configurations to meet the specific needs of your project.

Product Overview

The MDM Series connectors feature a receptacle with socket design, allowing for easy and secure connections. The contact material is made of copper alloy, providing excellent conductivity and durability. The contact plating is gold over nickel, ensuring reliable performance and resistance to corrosion.

The shell material is made of lightweight aluminum, making the MDM Series connectors ideal for applications where weight is a factor. The connectors are also designed to withstand extreme temperatures, with an operating range of -55 to +125°C, making them suitable for use in harsh environments.

Key Features

• Miniature size

• High density

• Lightweight

• Receptacle with socket design

• Copper alloy contact material

• Gold over nickel contact plating

• Aluminum shell material

• Operating temperature range of -55 to +125°C

• 25 contacts per connector

Applications

The MDM Series connectors are commonly used in the following applications:

• Military and aerospace

• High-tech electronics

• Communication systems

• Medical equipment

• Satellite systems

• Robotics

Conclusion

The MIL-DTL-83513 Micro-D Connectors provide a reliable and compact solution for your connectivity needs. With their miniature size, high density, and lightweight design, they are suitable for a wide range of applications. The copper alloy contact material and gold over nickel plating ensure excellent conductivity and durability, while the aluminum shell material and wide temperature range make them suitable for use in harsh environments. Choose the MDM Series for your next project and experience the high performance and reliability of these connectors.

Features:

• Product Name: MIL-DTL-83513 Micro-D Connectors

• Voltage Rating: 500V

• Connector Type: Micro-D

• Contact Material: Copper Alloy

• Operating Temperature: -55 To +125°C

• Coupling Nut Plating: Nickel

• Receptacle with Socket

• Rectangular Connectors

• Receptacle with Socket Contacts

• High-Density

• Miniature

• Military and Aerospace Applications

Technical Parameters:

Applications:

TUO HANG MIL-DTL-83513 Micro-D Connectors

TUO HANG J30J-25ZKSL is a high-performance Micro-D Connector from the MDM Series, designed to meet the rigorous requirements of military, aerospace, and defense applications. This rectangular connector is known for its space-saving and high-density features, making it the perfect choice for applications where size and weight are critical factors.

With a proven track record of durability and reliability, TUO HANG Micro-D Connectors are built to withstand harsh environments, including extreme temperatures, shock, and vibration. This makes them the preferred choice for critical missions and operations.

The J30J-25ZKSL model is manufactured in China and meets the MIL-DTL-83513 specifications. It has 25 contacts and can withstand up to 500 mating cycles, ensuring long-lasting and dependable performance.

Applications and Scenarios

• Military and defense equipment

• Aerospace and aviation systems

• Satellites and spacecraft

• Military vehicles and weapons

• Communications and navigation systems

• Radar and sonar equipment

• Missile guidance systems

TUO HANG Micro-D Connectors are designed to provide high-performance interconnect solutions for a wide range of applications. Their miniature size and high-density configuration make them ideal for use in tight spaces and complex systems. They are also compatible with various PCB mounting options, including solder cups, for easy installation.

Product Features

• Space-saving and high-density rectangular connectors

• Durable and reliable for use in harsh environments

• Meets MIL-DTL-83513 specifications

• 500 mating cycles

• 25 contacts

• Can withstand extreme temperatures (-55 to +125°C)

• Made of copper alloy for superior conductivity

• Nickel-plated coupling nut for corrosion resistance

In conclusion, TUO HANG MIL-DTL-83513 Micro-D Connectors, with their high-performance and rugged design, are the go-to choice for military, aerospace, and defense applications. Their superior quality and reliability make them a valuable asset for critical missions and operations. Choose TUO HANG for your interconnect needs and experience the best in miniature connector technology.
